Chabazite-K
A valid IMA mineral species
This page is currently not sponsored. Click here to sponsor this page.
About Chabazite-K
Formula:
(K2,Ca,Na2,Sr,Mg)2[Al2Si4O12]2 · 12H2O
Colour:
Colourless
Lustre:
Vitreous
Hardness:
4
Crystal System:
Trigonal
Member of:
Name:
Named in 1788 by Louis-Augustin Bosc d'Antic from the Greek chabazios, tune or melody, one of twenty stones named in the poem Peri lithos, which extolled the virtues of minerals. The poem is ascribed to Orpheus, legendary founder of the Orphic cult, which flourished in Greece in the early centuries. The suffix was added by the IMA in 1997 when chabazite (without suffix) was promoted to a series. It denotes the dominant extra-framework element.
Type Locality:
Unique Identifiers
Mindat ID:
6855
Long-form identifier:
mindat:1:1:6855:6
Similar Names
| Chabazite | A group of related mineral species | |
| Chabazite-Ca | A valid IMA mineral species | (Ca,K2,Na2)2[Al2Si4O12]2 · 12H2O |
IMA Classification of Chabazite-K
Classification of Chabazite-K
9.GD.10
9 : SILICATES (Germanates)
G : Tektosilicates with zeolitic H2O; zeolite family
D : Chains of 6-membered rings – tabular zeolites
9 : SILICATES (Germanates)
G : Tektosilicates with zeolitic H2O; zeolite family
D : Chains of 6-membered rings – tabular zeolites
Mineral Symbols
As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.
Please only use the official IMA–CNMNC symbol. Older variants are listed for historical use only.
Please only use the official IMA–CNMNC symbol. Older variants are listed for historical use only.
| Symbol | Source | Reference |
|---|---|---|
| Cbz-K | IMA–CNMNC | Warr, L.N. (2021). IMA–CNMNC approved mineral symbols. Mineralogical Magazine, 85(3), 291-320. doi:10.1180/mgm.2021.43 |
| Cbz | Kretz (1983) | Kretz, R. (1983) Symbols of rock-forming minerals. American Mineralogist, 68, 277–279. |
| Cbz | Siivolam & Schmid (2007) | Siivolam, J. and Schmid, R. (2007) Recommendations by the IUGS Subcommission on the Systematics of Metamorphic Rocks: List of mineral abbreviations. Web-version 01.02.07. IUGS Commission on the Systematics in Petrology. download |
| Cbz | Whitney & Evans (2010) | Whitney, D.L. and Evans, B.W. (2010) Abbreviations for names of rock-forming minerals. American Mineralogist, 95, 185–187 doi:10.2138/am.2010.3371 |
| Cbz | The Canadian Mineralogist (2019) | The Canadian Mineralogist (2019) The Canadian Mineralogist list of symbols for rock- and ore-forming minerals (December 30, 2019). download |
Pronunciation of Chabazite-K
Pronunciation:
| Play | Recorded by | Country |
|---|---|---|
| Jolyon Ralph | United Kingdom |
Physical Properties of Chabazite-K
Optical Data of Chabazite-K
Type:
Biaxial (+/-)
RI values:
nα = 1.478 - 1.485 nβ = 1.48 - 1.4895 nγ = 1.48 - 1.49
Max. Birefringence:
δ = 0.002 - 0.005
Based on recorded range of RI values above.
Based on recorded range of RI values above.
Interference Colours:
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
Surface Relief:
Moderate
Dispersion:
none
Chemistry of Chabazite-K
Mindat Formula:
(K2,Ca,Na2,Sr,Mg)2[Al2Si4O12]2 · 12H2O
Element Weights:
Crystallography of Chabazite-K
Crystal System:
Trigonal
Class (H-M):
3m (3 2/m) - Hexagonal Scalenohedral
Space Group:
R3m
Cell Parameters:
a = 13.831 Å, c = 15.023 Å
Ratio:
a:c = 1 : 1.086
Unit Cell V:
2,488.83 ų (Calculated from Unit Cell)
Morphology:
Comment:
Data from Yakubovic et al. (2005) (193 K).
Crystal Structure
Load
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Show
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Display Options
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
View
CIF File Best | x | y | z | a | b | c
CIF File Best | x | y | z | a | b | c
Rotation
Stop | Start
Stop | Start
Labels
Console Off | On | Grey | Yellow
Console Off | On | Grey | Yellow
Data courtesy of the American Mineralogist Crystal Structure Database. Click on an AMCSD ID to view structure
| ID | Species | Reference | Link | Year | Locality | Pressure (GPa) | Temp (K) |
|---|---|---|---|---|---|---|---|
| 0007149 | Chabazite-K | Gualtieri A F, Passaglia E (2006) Rietveld structure refinement of NH4-exchanged natural chabazite European Journal of Mineralogy 18 351-359 | 2006 | Wasson's Bluff, Two Islands, Nova Scotia, Canada | 0 | 293 | |
| 0012392 | Chabazite-K | Yakubovich O V, Massa W, Gavrilenko P G, Pekov I V (2005) Crystal structure of chabazite K Crystallography Reports 50 544-553 | 2005 | Khibiny alkaline massif, Kola Peninsula, Russia | 0 | 293 | |
| 0017688 | Chabazite-K | Alberti A, Galli E, Vezzalini G, Passaglia E, Zanazzi P F (1982) Position of cations and water molecules in hydrated chabazite. Natural and Na-, Ca-, Sr- and K-exchanged chabazites Zeolites 2 303-309 | 1982 | Keller, Nidda, Germany | 0 | 293 |
CIF Raw Data - click here to close
X-Ray Powder Diffraction
Powder Diffraction Data:
| d-spacing | Intensity |
|---|---|
| 2.929 Å | (very strong) |
| 9.420 Å | (strong) |
| 4.343 Å | (strong) |
| 3.892 Å | (moderately strong) |
| 3.612 Å | (moderately strong) |
| 5.053 Å | (moderate) |
| 4.004 Å | (moderate) |
| 2.620 Å | (moderate) |
| 2.516 Å | (moderate) |
| 2.104 Å | (moderate) |
| 1.814 Å | (moderate) |
Comments:
Ercolano, Mount Somma, Italy. Data are from de Gennaro and Franco (1976).
Geological Environment
Paragenetic Mode(s):
| Paragenetic Mode | Earliest Age (Ga) |
|---|---|
| Stage 3a: Earth’s earliest Hadean crust | >4.50 |
| 9 : Lava/xenolith minerals (hornfels, sanidinite facies) | |
| 10 : Basalt-hosted zeolite minerals | |
| Stage 3b: Earth’s earliest hydrosphere | >4.45 |
| 17 : Marine authigenic Hadean minerals (see also #24) | |
| Near-surface Processes | |
| 22 : Hydration and low-? subsurface aqueous alteration (see also #23) | |
| 24 : Authigenic minerals in terrestrial sediments (see also #17) | |
| Stage 5: Initiation of plate tectonics | <3.5-2.5 |
| 40 : Regional metamorphism (greenschist, amphibolite, granulite facies) |
Type Occurrence of Chabazite-K
Place of Conservation of Type Material:
No designated type material.
Synonyms of Chabazite-K
Other Language Names for Chabazite-K
Relationship of Chabazite-K to other Species
Member of:
Other Members of Chabazite:
| Chabazite-Ca | (Ca,K2,Na2)2[Al2Si4O12]2 · 12H2O | Tric. 1 : P1 |
| Chabazite-Mg | (Mg0.7K0.5Ca0.5Na0.1)[Al3Si9O24] · 10H2O | Trig. 3m (3 2/m) : R3m |
| Chabazite-Na | (Na2,K2,Ca,Sr,Mg)2[Al2Si4O12]2 · 12H2O | Trig. 3m : R3m |
| Chabazite-Sr | Sr2[Al2Si4O12]2 · 12H2O | Trig. 3m (3 2/m) : R3m |
Common Associates
Associated Minerals Based on Photo Data:
| 31 photos of Chabazite-K associated with Chabazite-Ca | (Ca,K2,Na2)2[Al2Si4O12]2 · 12H2O |
| 29 photos of Chabazite-K associated with Phillipsite-K | K6(Si10Al6)O32 · 12H2O |
| 18 photos of Chabazite-K associated with Offretite | KCaMg(Si13Al5)O36 · 15H2O |
| 13 photos of Chabazite-K associated with Calcite | CaCO3 |
| 10 photos of Chabazite-K associated with Thomsonite-Ca | NaCa2[Al5Si5O20] · 6H2O |
| 10 photos of Chabazite-K associated with Stilbite-Ca | NaCa4(Si27Al9)O72 · 28H2O |
| 8 photos of Chabazite-K associated with Gismondine Subgroup | |
| 6 photos of Chabazite-K associated with Vonsenite | Fe2+2Fe3+(BO3)O2 |
| 3 photos of Chabazite-K associated with Fluorapatite | Ca5(PO4)3F |
| 3 photos of Chabazite-K associated with Saponite | Ca0.25(Mg,Fe)3((Si,Al)4O10)(OH)2 · nH2O |
Related Minerals - Strunz-mindat Grouping
| 9.GD.05 | Gmelinite-Ca | Ca2(Si8Al4)O24 · 11H2O |
| 9.GD.05 | Gmelinite-K | K4(Si8Al4O24) · 11H2O |
| 9.GD.05 | Gmelinite-Na | Na4(Si8Al4)O24 · 11H2O |
| 9.GD.10 | Chabazite-Mg | (Mg0.7K0.5Ca0.5Na0.1)[Al3Si9O24] · 10H2O |
| 9.GD.10 | Willhendersonite | KCa[Al3Si3O12] · 5H2O |
| 9.GD.10 | Chabazite-Ca | (Ca,K2,Na2)2[Al2Si4O12]2 · 12H2O |
| 9.GD.10 | Chabazite-Na | (Na2,K2,Ca,Sr,Mg)2[Al2Si4O12]2 · 12H2O |
| 9.GD.10 | Chabazite-Sr | Sr2[Al2Si4O12]2 · 12H2O |
| 9.GD.15 | Lévyne-Ca | (Ca,Na2,K2)[Al2Si4O12] · 6H2O |
| 9.GD.15 | Lévyne-Na | (Na2,Ca,K2)[Al2Si4O12] · 6H2O |
| 9.GD.20 | Erionite-Ca | (Ca,K2,Na2)2[Al4Si14O36] · 15H2O |
| 9.GD.20 | Erionite-K | (K2,Ca,Na2)2[Al4Si14O36] · 15H2O |
| 9.GD.20 | Erionite-Na | (Na2,K2,Ca)2[Al4Si14O36] · 15H2O |
| 9.GD.20 | Bellbergite | (K,Ba,Sr)2Sr2Ca2(Ca,Na)4[Al3Si3O12]6 · 30H2O |
| 9.GD.25 | Offretite | KCaMg(Si13Al5)O36 · 15H2O |
| 9.GD.25 | Wenkite | (Ba,K)4(Ca,Na)6[(Si,Al)20O39(OH)2](SO4)3 · 0.5H2O |
| 9.GD.30 | Faujasite-Ca | (Ca,Na2,Mg)3.5[Al7Si17O48] · 32H2O |
| 9.GD.30 | Faujasite-Mg | (Mg,Na2,Ca)3.5[Al7Si17O48] · 32H2O |
| 9.GD.30 | Faujasite-Na | (Na2,Ca,Mg)3.5[Al7Si17O48] · 32H2O |
| 9.GD.35 | Maricopaite | Pb7Ca2(Si,Al)48O100 · 32H2O |
| 9.GD.35 | Mordenite | (Na2,Ca,K2)4(Al8Si40)O96 · 28H2O |
| 9.GD.40 | Dachiardite-K | K4(Si20Al4O48) · 13H2O |
| 9.GD.40 | Dachiardite-Ca | (Ca,Na2,K2)5Al10Si38O96 · 25H2O |
| 9.GD.40 | Dachiardite-Na | (Na2,Ca,K2)5Al10Si38O96 · 25H2O |
| 9.GD.45 | Epistilbite | CaAl2Si6O16 · 5H2O |
| 9.GD.50 | Ferrierite-K | (K,Na)5(Si31Al5)O72 · 18H2O |
| 9.GD.50 | Ferrierite-Mg | [Mg2(K,Na)2Ca0.5](Si29Al7)O72 · 18H2O |
| 9.GD.50 | Ferrierite-Na | (Na,K)5(Si31Al5)O72 · 18H2O |
| 9.GD.50 | Ferrierite-NH4 | (NH4,Mg0.5)5(Al5Si31O72) · 22H2O |
| 9.GD.55 | Bikitaite | LiAlSi2O6 · H2O |
Radioactivity
Other Information
Health Risks:
No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.
Internet Links for Chabazite-K
mindat.org URL:
https://www.mindat.org/min-6855.html
Please feel free to link to this page.
Please feel free to link to this page.
Search Engines:
External Links:
References for Chabazite-K
Reference List:
Passaglia, Elio (1970) The crystal chemistry of chabazites. American Mineralogist, 55 (7-8) 1278-1301
Alberti, A., Galli, E., Vezzalini, G., Passaglia, E., Zanazzi, P.F. (1982) Position of cations and water molecules in hydrated chabazite. Natural and Na-, Ca-, Sr- and K-exchanged chabazites. Zeolites, 2 (4) 303-309 doi:10.1016/s0144-2449(82)80075-4
Coombs, Douglas S., Alberti, Alberto, Armbruster, Thomas, Artioli, Gilberto, Colella, Carmine, Galli, Ermanno, Grice, Joel D., Liebau, Friedrich, Mandarino, Joseph A., Minato, Hideo, et al. (1997) Recommended nomenclature for zeolite minerals; report of the Subcommittee on Zeolites of the International Mineralogical Association, Commission on New Minerals and Mineral Names. The Canadian Mineralogist, 35 (6). 1571-1606
Neuhoff, Philip S., Stebbins, Jonathan F., Bird, Dennis K. (2003) Si-Al disorder and solid solutions in analcime, chabazite, and wairakite. American Mineralogist, 88 (2) 410-423 doi:10.2138/am-2003-2-317
Localities for Chabazite-K
symbol to view information about a locality.
The Locality List
- This locality has map coordinates listed.
- This locality has estimated coordinates.
ⓘ - Click for references and further information on this occurrence.
? - Indicates mineral may be doubtful at this locality.
- Good crystals or important locality for species.
- World class for species or very significant.
(TL) - Type Locality for a valid mineral species.
(FRL) - First Recorded Locality for everything else (eg varieties).
All localities listed without proper references should be considered as questionable.
